- 10-inch 12K mono LCD display
- XY resolution 19×24 μm
- Construction volume 218,88×122,88×250 mm³
- Print speed up to 70 mm/h
- COB + Fresnel collimation lens
- Laser cut build plate
Key Features:
- 【10-inch 12K mono LCD display】With a 10-inch 12K mono LCD display with an incredible resolution of 11520×5120 and XY resolution of 19×24μm, ELEGOO Saturn 3 is able to produce highly detailed and intricate patterns with ease, at print speeds up to 70mm/h. Tempered glass with 9H hardness protects the LCD screen from scratches and damage caused by dripping or resin penetration.
- 【Generous build volume】With a generous build volume of 218.88×122.88×250 mm³/8.62×4.84×9.84 inches, you can try printing larger models and more ambitious designs for greater flexibility and versatility.
- 【Fresnel Collimating Light Source】The COB light source and the Fresnel collimating lens work together to emit a uniform 405 nm wavelength light beam, and ensure that the illumination angle reaches up to 5°, the light uniformity is over 90%, and the light scattering coefficient is within 0.5%. This results in extremely accurate and consistent prints with exceptional clarity and detail.
- 【Laser Cut Building Plate】Building plate with laser cut surface provides excellent adhesion, ensuring your prints stick to the building plate for a higher print success rate.
- 【Voxeldance Tango Software】It offers 3 printing modes: static mode and dynamic mode (including smooth mode and high-speed mode) to improve printing efficiency. The open source GOO slicer file format is compatible with third-party slicer software such as CHITUBOX and Lychee Slicer.
- 【Included Air Purifier】The advanced USB air purifier with built-in activated carbon filter and plastic protective case ensures that harmful odor is purified during printing. You can also opt for the upcoming ELEGOO Mars MATE air purifier, which can remove up to 95% of VOCs for a safer working environment.
ELEGOO Saturn 3 MSLA 3D Printer
Printing accuracy 12K
The ELEGOO Saturn 3 uses a 10-inch 12K mono LCD display with 11520×5120 resolution and 19×24 micron XY resolution, enabling the production of intricate patterns with excellent detail and exceptional sharpness. Replaceable 9H tempered glass effectively prevents scratching and damaging the LCD screen and extends its life.
COB + Fresnel collimating lens
The COB light source combined with a Fresnel collimating lens provides a more perpendicular and uniform exposure across the entire screen, within a 5 degree light angle and 0.5% light scattering coefficient, as well as 90% light uniformity, allowing you to print truly impressive patterns with smooth surfaces and sharp edges.
Advanced heat removal system
The improved heat dissipation system includes 6 dual heat conducting copper tubes and 4 cooling fans on either side of the light source for faster ventilation and better heat dissipation. This ensures that your printer performs at its best, extending its life.
High stable structure
The dual linear guide rail design ensures that the Z-axis motion is quieter, more stable and precise, which reduces ripple on final prints. Laser cut build plate with excellent adhesion ensures your prints stick to the build plate even when printing large patterns. The non-slip hex socket levelling screws are designed for easy handling, making levelling quick and easy. The middle plate of the printer is designed with a raised step that prevents resin from leaking inside the printer, keeping your machine’s components safe and clean.
Multiple print modes
The Voxeldance Tango software is designed to improve printing efficiency by offering static and dynamic print modes (dynamic mode includes smooth mode and high-speed mode). With the open source GOO slicer file format, you can use third-party slicing software, such as CHITUBOX and Lychee Slicer, for added flexibility and convenience.
Odourless printing medium
The safety of your print is our concern, so we’ve included an improved USB-powered air purifier with a plastic protective case that effectively protects the built-in activated carbon filter from damage and breakage during transport. For added peace of mind, you can also choose the upcoming ELEGOO Mars MATE air purifier, which can remove up to 95% of VOCs for a safe and comfortable workspace.
