FiberFlex 30D – Grey – Fiberlogy TPU 0.500 kg

FiberFlex 30D – Grey – Fiberlogy TPU 0.500 kg

BE MORE FLEXIBLE.

Another option for the enthusiasts of printing on elastic materials. FIBERFLEX 30D is characterized by reduced hardness to 30D on the Shore scale, very good flexibility and higher impact strength.

The material is recommended for printing on tyres, seals, belts and any elastic elements.

APPLICATIONS:

• RUBBER ELEMENTS: seals, elements that often bend
• GIFT ITEMS OR ELEMENTS THEREOF: phone cases, watch straps, heart rate monitors, pedometers
• RELATED ITEMS: flexible hinges
• TOYS OR THEIR ELEMENTS: tyres, rubber figures
• JEWELLERY: bands, bracelets

Properties:

• 30D Shore hardness
• high impact resistance at low temperatures
• very good thermal, chemical and abrasion resistance

How to print?

*The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to select the appropriate settings for a specific printer and printing conditions.

FiberFlex 30D – Grey – Fiberlogy TPU 0.500 kg :

• Nozzle temperature 200-220°C
• Bed temperature 50-70°C
• No closed chamber required
• Fan 50-75%
• Flow rate 105-110%
• Print speed < 35 mm/s
• Surface glass, masking tape
• Retraction (direct) 1-2 mm
• Retraction speed 10-30 mm/s
• Remarks For easier removal of the print it is recommended to heat the bed to 110°C.

Additional information:

– print speed up to 45 mm/s with direct extruder
– can be printed with Bowden extruder at 15-30 mm/s
– for easier removal of the print it is recommended to heat the bed to 110°C
