CPE HT – Black – Fiberlogy
THE LATEST GENERATION OF COPOLYESTERS
CPE HT filament is a modern copolyester that features high mechanical and temperature resistance.
As a member of the polymer family, which includes PET-G and PCTG, it outperforms them in terms of resistance to high temperatures, even up to 110°C. Like other related materials, this filament has high resistance to chemicals and lipids.
It is odorless and free of BPA, BPS and styrene and can be used to create food contact parts*. CPE HT will find numerous applications that require resistance to degrading conditions, such as in a dishwasher or in a chemical sterilization or UV radiation process.
Fiberlogy CPE HT is an attractive alternative to polycarbonate filaments. Possessing similar strength parameters as PC, it does not share with it the characteristics that make it difficult to use.
| Nozzle temperature | 260-280°C |
| Bed temperature | 110-120°C |
| Closed chamber | not necessary |
| Fan | 0-25% |
| Flow rate | 95-105% |
| Print speed | less than 100 mm/s |
| Surface | paper tape, PVA glue, hairspray |
| Retraction (direct extrusion) | 1-2 mm |
| Retraction (Bowden) | 4-6 mm |
| Speed of retraction | 20-45 mm/s |
| Drying conditions | 60°C for 4 hours |
| Notes | Due to the strong adhesion to the bed, direct printing on its surface or on glass is not recommended. This can cause damage. We recommend the use of paper tape. |
| Profiles | Bambu Lab X1C – Fiberlogy-CPE-HT-BambuLab |
APPLICATION IN 3D PRINTING OF CPE HT Filament :
- HOME USE: food storage containers, reusable containers
- CHILDREN’S PRODUCTS: toys and spare parts, baby accessories
- BUDGET APPLIANCES: appliance housings, spare parts, prototypes for use, water filters
Properties:
- temperature resistance up to 110°C
- odourless
- BPA, BPS and styrene free
- high mechanical strength comparable to PC
How to print?
The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to select the appropriate settings for a specific printer and printing conditions.
- Nozzle temperature 260-280°C
- Bed temperature 110-120°C
- No closed chamber required
- Fan 0-25%
- Flow rate 95-105%
- Print speed < 100 mm/s
- Surface masking tape, PVA adhesive
- Retraction (direct) 1-2 mm
- Retraction (Bowden) 4-6 mm
- Retraction speed 20-45 mm/s
- Drying conditions 60°C / 4h
- Remarks Due to good adhesion it is not recommended to print directly on the bed surface or on glass. This can lead to failure. We recommend using masking tape.
