D1000 CreatBot
One cubic meter large industrial-grade 3D printer.
The D1000 is an upgrade from the F1000 model. With a build volume of over 1000 x 1000 x 1000 mm, it is the ideal machine for creating large and full-size parts, prototypes, tools, dies, jigs and fixtures in the enterprise. Within a few days you can have a fully functional high quality prototype. CreatBot’s large spools of filament in PLA, ABS, ASA, PA-CF, etc. are suitable for your large models without worrying about frequent filament replacement. All its features are manufactured to the highest standards. Every time, on every part, without error.
Faurecia is a global provider of engineering solutions and equipment for advanced automotive systems. They use the CreatBot D1000 3D printer model to design and develop moulds for car seats and are widely used in Audi, VW, NISSAN and GM engines. The shapes in the video are their typical 3D printing product produced with the D1000 3D printer. The bowl and lid are required to withstand 100MPa, we choose nylon and carbon fiber materials with 50% filling for the production. Finally, the footprint performance is exclusive and passes their rigorous tests!
Worry-free size for high strength prototypes
The CreatBot D1000 is designed to make industrial 3D printing of large objects and prototypes as easy as possible. It incorporates many advanced technologies for extremely large and impressive footprints. It will be your best choice without a doubt, if you are looking for an industrial large-scale 3D printer for prototypes and engineering materials.
If you’re tired of the brittleness of PLA and the deformation of ABS, try our revolutionary UltraPA-CF material. Print your large size model with large size nozzle, in a few days you will get an oversized model with high strength 80MPa and temperature resistance 150°C. The best choice for checking your prototype.
Automatic rising two extruders 420℃
The D1000 incorporates a new intelligent kit with an automatic rising double extruder with a chotemde temperature of up to 420℃, chotemde
can be replaced with another size quickly. it is able to print not only huge PLA+ water soluble PVA materials
for the prototype with the fastest speed, but also ABS, PC, nylon, carbon fiber, flexible and other high-grade materials.
materials for direct application. The double heating mechanism is easy to maintain and accessible for replacement.
Interrupt recovery and thread recognition
The printer automatically remembers the current position and saves the print data. Lower the platform and retrieve the thread when the power is suddenly turned off. It will continue printing from the last stop point after power is turned on. No trace! The printer will avoid an invalid print by stopping the print and warning when the filament runs out.
Linear rail and servomotors
When the length reaches over 1000 mm, the small rail has a large deviation. The structure of D1000 precision linear rail is very thick and strong. It will not warp or lose precision after millions of strokes of the print head.
With servomotors, timeliness, quick response, no inertia, no delay is achieved. closed loop position control overcomes the problem of pitch loss. heat and noise are significantly reduced. It gives the printing model ultra-high performance with high speed.
Hot chamber + dryer for filaments
The 60°C hot chamber ensures print quality for high-quality materials. A fully enclosed chamber can block all external interference. Also, this frame can reduce noises while ensuring a constant temperature so that the model does not deform.
The filament drying room provides chamber temperatures of 45°C and 65°C for drying 2*5kg/roll of filaments such as PLA, nylon, PC, ABS and other materials with water absorption.
Platform with automatic levelling
Using 100 points through the high-precision servo probe to preserve the platform flatness data at the top, through the intelligent Z-axis table height compensation in the printing process to achieve fully automatic leveling.
HEPA air filter
The air filtration system can adsorb the dirt and gas generated by the printing of special filaments such as ABS, nylon, PC, safer and more environmental protection, which are more suitable for home, school, office.
Camera control technology
Camera control technology allows customers to control the printing process of speed, pause, temperature, etc. using APP remotely, which can lead to the best printing quality with the shortest time without failure. Very useful feature for large pattern and long lasting print.
- CREATBOT D1000
- 1000*1000*1000 mm
- High resolution and speed
- Camera control technology
- Reliable 24/7
- Fully enclosed
Stability
The all-steel housing not only provides stability during printing, but also significantly extends the service life. The optimization and collaboration of the overall structure ensures sustainable and efficient operation. The first batch of CreatBot 3D printers with all-steel housing has been running for 9 years and more than 30,000 hours.
Affordable and reliable large 3D printer
CreatBot D1000 is designed to make industrial 3D printing of large objects and prototypes as easy as possible. This is an industrial 3d printer that meets market demand and is built with a new smart kit with dual extruder, enclosed heated chamber, auto-leveling system and camera control for large, impressive, prints. Camera control technology allows customers to control the printing process using APP, which can get the best print quality with the shortest time without failure. With a fast-heating platform and hot chamber, this high-resolution large-format printing workhorse produces incredible results with high-quality materials. The CreatBot D1000 sets a new standard in additive manufacturing and expands the material capabilities of large-scale 3d printers, it brings the ability to significantly reduce costs and time for more companies.
CreatBot D1000 will undoubtedly be your best choice if you are looking for an industrial large scale 3d printer for engineering quality prototypes and materials.
Most importantly, it is AVAILABLE for any company!
Printing in single and double extrusion mode
Technical characteristics
- Printing technology Fused deposition modelling
- Volume of the structure in single extrusion: 1000*1000*1000 mm
- Double extrusion: 940*1000*1000 mm
- Number of nozzles Automatically rising double extruders
- Layer resolution 0,05 mm
- Thread diameter 1,75 mm
- Filament compatibility ABS, PLA, carbon fiber, PETG, nylon, PC, etc.
- Nozzle diameter 1.0 mm（0.4~1.5 mm optional）
- Print file type STL, OBJ, AMF, Gcode
Speed
- Best print speed 60 mm/s
- Max. Print speed 120 mm/s
Software
- Software CreatWare, Simplify 3D, Cura, Slic3r, etc.
- Supported file types STL, OBJ, Gcode, AMF
- Operating systems Windowsall, macOS
Special feature
- Restored interrupt Save data at power off
- Filament detection Stop printing when you run out of filament
- Auto Power Off Turn off the power automatically when printing is complete
- Camera control Remote camera monitoring and real-time control of the printing process
Temperature
- Max. Nozzle temperature 420℃
- Max. Bed temperature 100℃
- Hot chamber temperature 60℃
- Drying room temperature for strands 45℃/65℃
Mechanical
- Construction Energy coated steel, aluminium casting for motion components, POM
- Building Plate Aluminium Plates For Aviation
- Automatic leveling of the build plate
- Extruder Intelligent twin extruders
- Stepper motors 1.8° step angle with 1/16 microstep
- Positioning precision X Y 0.011 mm
- Positioning precision Z 0,0025 mm
Electric
- Power requirements 220~240 V, 50~60 Hz
- Screen 9.7-inch full-color touch screen independent operating system (multilingual)
- Rated printer power: 4000 W, camera: 4500 W
- Storage media U disk
- USB connection
Size and weight
- Product dimensions and weight 1810*1350*1942mm 650kg
- Package dimensions and weight 1980×1520×2200mm 750kg
