A1 mini Combo (AMS included) Bambu Lab

A1 mini Combo (AMS included) Bambu Lab

Active flow compensation function

The A1 mini revolutionizes flow control in 3D printing. Our algorithm actively compensates the flow rate according to the readings to extrude with accuracy.

A1 mini Technical specifications

Corpus

Housing volume: 180*180*180 mm³
Chassis: Steel + extruded aluminium

Instrument head
Host: all metal
Extruder gear: steel
Nozzle: stainless steel
Maximum Hotend temperature: 300℃
Nozzle diameter (included): 0.4 mm
Nozzle diameter (optional): 0.2 mm, 0.6 mm, 0.8 mm
Thread cutting part: yes
Thread diameter: 1,75 mm

Heating bed:
Compatible Building Plate: Bambu Textured PEI Plate ; Bambu Smooth PEI Plate
Maximum plate temperature for construction: 80℃

Speed

Maximum tool head speed: 500 mm/s
Maximum tool head acceleration: 10 m/s²
Maximum hot end flow: 28 mm³/s @ABS (Model: 150*150 mm single wall;

Material:Bambu ABS; Temperature:280℃)

Cooling
Part cooling fan: closed loop control
Hotend fan: closed-loop control
MC board cooling fan: closed loop control

Maintained thread
PLA, PETG, TPU, PVA: ideal
ABS, ASA, PC, PA, PET, carbon/glass fiber reinforced polymer: Not recommended

Sensors

Surveillance camera: low speed camera (up to 1080P) Time interval supported
Thread exhaust sensor: yes
Thread odometry: yes
Power Loss Recovery: yes
Thread tangle sensor: yes

Physical dimensions
Dimensions: 347*315*365 mm³
Net weight: 5,5 kg

Electrical characteristics
Input voltage: 100-240 VAC, 50/60 Hz
Maximum power: 150 W

Electronics
Display: 2.4-inch 320*240 IPS touch screen
Connectivity: Wi-Fi, Bambu-Bus
Storage: micro SD card
Control Interface: touch screen, APP, PC application
Motion controller: dual-core Cortex M4

Software
Slicer: BambuudioSupport third-party sliders that export standard
Gcode, such as Superslicer, Prusaslicer and Cura, but some

advanced features may not be supported.
Supported operating systems: macOS, Windows

Wi-Fi
Frequency range: 2412 MHz – 2472 MHz (CE)

2412 MHz – 2462 MHz (FCC)

2400 MHz – 2483.5 MHz (SRRC)
Transmitter power (EIRP): ≤ 21.5 dBm (FCC)

≤ 20 dBm (CE/SRRC)
Protocol: IEEE 802.11 b/g/n

What’s in the box

Frequently Asked Questions

1.What is the difference between AMS and AMS lite? Does AMS lite work with any Bambu printer or even other printers (brand)?

A: AMS is closed and AMS lite is not closed.
AMS is incompatible with A1 mini. If you want multicolor printing with A1 mini, you need to use AMS lite.
AMS lite is incompatible with the X1 or P1 printer and other (branded) printers. If you want multicolor printing using an X1 or P1 printer, you must use AMS. For more information, please check here.

2.What materials can A1 mini print?

A: A1 mini can print most of the materials on the market that do not require a housing, such as PLA, PETG, TPU and their supporting filaments. It is not recommended to print filaments such as ABS, ASA, PC, PA and PET which require higher bed and chamber temperatures. for more details, please check here.

3.What is the maximum footprint size of A1 mini?

A: 180*180*180 mm. For more product specifications, please see this page. For more details, please check here.
